Antop RF Splitter AT-708 6-way 2GHz
$28.99
Splits signal to up to 6 TVs
18K Gold-Plated Chassis
Low Insertion Loss
High Return Loss
Lower Noise
Higher Signal Quality
Compatible with Satellite / TV RF Signals
Product Description
Introduction
The Antop 6-ways Splitter AT-708 splits a single incoming coaxial signal, such as satellite signal, over-the-air HD (digital TV) antenna signal, into six outgoing signals.
Precision zinc die-cast with 18K gold-plated chassis for maximum signal transfer, corrosion resistance, and reliable connectivity.
All ports DC Power Passing enables DC power from all outputs to pass the power to the input (or in the opposite direction). Thus all satellite receivers can supply LNB power, while all amplified outdoor antenna or masthead amplifier can be powered from the interior power supply devices. Care should be taken to ensure the input of a receiver will not be damaged by power from another receiver. Reverse powering protection is provided in many receivers and systems.
Product Information
- All ports female F connector 75 Ohm
- All ports DC power pass
Specification
Specification | |
| Usage | Indoor |
|---|---|
| Screening factor | 5-300MHz≥75dB,300-470MHz≥75dB, 470-1000MHz≥65dB,1000-2050MHz≥55dB |
| Insertion Loss | 11dB (5-47MHz),12dB (47-1000MHz),13.5dB (1000-1750MHz),14.5dB (1750-2050MHz) |
| Isolation | 20dB (5-2050MHz) |
| Return Loss | 10dB (5-47MHz),, 12dB (5-2050MHz) |
| Receiving Range | TV/SAT |
| Impedance | 75Ω |
| All Port DC Pass | 24V/200mA (max.) |
| Product Series | Splitters |
| UPC | 856134006278 |
Consumer Packaging | |
| Weight | 0.25 lbs |
|---|---|
| Dimensions | 6.55 × 3.26 × 0.91 in |
